The Black Diamond Path Light is  available without a lamp to be installed. Simply install the lamp and screw on the Black Diamond Path Light top. The threaded top design allows the top to stay straight on the fixture, and also includes a white reflective surface underneath. The spun brass construction features a baked enamel finish. Overall height is 18.25”.

PATH LIGHT

AN ECONOMICAL OPTION FOR BUDGET CONSCIOUS PROJECTS

Available in Black Brass Baked Enamel

Easy to Install: Install Lamp, Screw Top onto Stem, and Install

Includes ABS Mounting Stake

Use for Path, Area, and Garden Accent Lighting Threaded

Top Design Stays Straight on the Fixture Top Design Includes White Reflective Surface Underneath

10 year warranty

The Black Diamond Path Light has a Black Brass Baked Enamel finish.

To clean the fixture, periodically wipe it down with a mild soap and water.

SOFT SOIL APPLICATIONS: INSTALLING THE GROUND STAKE & FIXTURE

1. Connect the power cable from the fixture body to the landscape cable.

2. Lay the power cable into the slotted relief on the stake.

3. Press the fixture and stake into the ground.

4. Use a level to ensure the top of the stake is level with the ground.

HARD SOIL APPLICATIONS: INSTALLING THE GROUND STAKE & FIXTURE

1. Unscrew the fixture body from the stake.

2. Dig a hole approximately 4” wide by 10” deep and gently tap the stake into the ground with a rubber mallet.

3. Use a level to ensure the top of the stake is level with the ground.

4. Reinstall the fixture body onto the stake and lay the power cable into the slotted relief on the stake.

5. Connect the power cable from the fixture body to the landscape cable.

INSTALLING THE LAMP

1. Loosen the threaded jam nut toward the stem.

2. Unscrew the lid from the stem.

3. Install the Beacon G4 Bi-Pin into the socket.

4. Screw the lid onto the stem.

5. Adjust the threaded ring until you achieve the light pattern you want.
